A motorized microscope with episcopic/diascopic illumination ,which meets the various needs of observation, inspection, research, and analysis ac
ross a wide range of industrial fields. Higher NA and a longer working distance than ever before mean superior optical performance and efficient digital imaging.
Max. sample size: 150 x 100 mm
Compatible with brightfield, darkfield, simple polarizing, DIC, epifluorescence and two-beam, interferometry observations. Furthermore, phase contrast and DIC observation with diascopic illumination are also possible.
It supports diverse and advanced research, analysis and inspection.
*Select suitable lens for each observation
CFI60-2 series offers higher NA and longer working distances than ever before.
Objectives for brightfield observation (epi)
Combining the camera control unit with the LV100DA-U, allows greater information detection and control over a variety of key functions, including the use of objective lenses, light intensity of the illumination unit, aperture stop, observation method adjustment (brightfield/darkfield/fluorescence) and magnification.
In addition, the information is automatically converted to appropriate calibration data when changing magnification.
| Base unit: | Maximum sample height: 33 mm (when used with LVNU5AI U5AI nosepiece and LV-S32 3x2 stage / LV-S64 6x4 stage) * 73 mm when used with one column riser 12V50W internal power source for dimmer, coarse and fine adjustment knobs Left: coarse and fine adjustment / Right: fine adjustment, 40 mm stroke Coarse adjustment: 14 mm/turn (with torque adjustment, refocusing mechanism) Fine adjustment: 0.1 mm/turn (1 μm/graduation) Stage mounting hole intervals: 70 x 94 (fixed by 4-M4 screw) |
|---|---|
| Nosepieces: | LV-NU5 Motorized Universal Quintuple Nosepiece (High-durability motorized 5-hole universal nosepiece) |
| Episcopic Illuminator: | LV-UEPI2A LV-LH50PC 12V50W Precentered Lamphouse HG precentered fiber illuminator: C-HGFIE (with light adjustment: PC controlled) *option Motorized operation and control of illumination selector turret Motorized aperture stop linked to brightfield/ darkfield selector (automatic optimization matched to objective lens), field diaphragm (centerable) Accepts ø 25 mm filter (NCB11, ND16, ND4), polarizer/analyzer, λ plate, excitation light balancer; equipped with noise terminator |
| Diascopic Illumniator: | LV-LH50PC 12V50W Precentered Lamphouse (Fly Eye optical system) Internal aperture, field diaphragm, filter (ND8, NCB11); transmitted/ reflected selector switch; 12V100W also available (option) |
| Eyepiece tubes: | LV-TI3 trinocular eyepiece tube ESD (Erected image, FOV: 22/25) LV-TT2 TT2 tilting trinocular eyepiece tube (Erected image, FOV: 22/25) C-TB binocular tube (Inverted image, FOV: 22) P-TB Binocular Tube (Inverted image, FOV: 22) P-TT2 Trinocular Tube (Inverted image, FOV: 22) |
| Stages: | LV-S32 3x2 stage (Stroke: 75 x 50 mm with glass plate) ESD compatible LV-S64 6x4 stage (Stroke: 150 x 100 mm with glass plate) ESD compatible LV-S6 6x6 stage (Stroke: 150 x 150 mm) ESD compatible |
| Eyepieces: | CFI eyepiece series |
| Objective lenses: | Industrial Microscope CFI60-2/CFI60 optical system Objective lens series: Combinations in accordance with the observation method |
| ESD performance: | 1000 to 10V, within 0.2 sec. (excluding certain accessories) |
| Power consumption: | 1.2A/90W |
| Weight: | Approximately 10kg |
