Nikon's Eclipse polarizing microscopes are renowned for their abilitiy to produc
e brighter, clearer, and higher contrast images. The LV100N POL, available in diascopic and episcopic microscope illumination types, continues this tradition and offers a completely reengineered base for even easier operation. The newly developed high-intensity 50W halogen light source is brighter than a conventional 100W halogen lamp. Low power consumption means less heat generation, thereby reducing the chance of heat-induced focus drift.
The new high intensity 50W halogen light source incorporates a fly-eye lens design that outputs more light than a 100W lamp. The greater brightness is achieved by optimizing the lamp filament size and optically expanding the size of the light source within the pupil illumination fulfillment.
The new CFI LU Plan Fluor EPI P objective series uses eco-glass that is manufactured to the same specifications as Nikon's proprietary infinity optics (CFI60) system, but without harmful substances such as lead and arsenic.
The focus stroke has been improved to 30mm, facilitating observation of tall samples.
The Bertrand lens enables both the observation and capture of conoscopic and orthoscopic images. The Bertrand lens is also focusable and centerable.
The high precision slider-type analyzer located in the intermediate tube is rotatable for a full 360°.
Focus drift resulting from light source heat is greatly reduced by virtue of the lower power consumption and heat generated from the new diascopic light source.
The stage is large-sized, pre-adjusted and click-stops in 45° increments, making it extremely accurate and easy to rotate. Because the stage is designed to be supported from the bottom of the microscope near the optical axis and incorporates steel cross roller guides, it is twice as stable and durable as conventional stages.
The large sized circular stage is supported near the optical axis and incorporates steal cross roller guides making the stage twice as stable and durable as conventional models. The stage is also extremely accurate, centerable to the optical axis, and provides click-stops at 45° increments.
| Main Body - Optical System: | CFI60 infinity |
|---|---|
| Main Body -Illumination: | 12V-50W halogen lamp; 12V-50W DC transformer built-in; Diascopic/Episcopic illuminationchangeover switch; Fly-eye lens; NCB11, ND8 filters built-in; 12V-100W type optional (requires external power supply) |
| Main Body - Focusing: | Coaxial coarse/fine focus knob; Focus stroke: 30mm; Coarse: 14mm per rotation; Fine: 0.1mm; Minimum reading: in 1µm increments |
| Eyepiece: | 10x (F.O.V. 22mm) |
| Eyepiece Tube: | P-TT3 Trinocular Tube for polarizing microscopy; P-TB2 Binocular Tube for polarizing microscopy |
| Intermediate Tube: | Built-in focusable Bertrand lens removable from optical path; Switchable Conoscopic/Orthoscopic observations; Analyzer built-in; Plate/compensator slot |
| Analyzer: | 360° rotary dial; Minimum reading angle 0.1° |
| Nosepiece: | Centering quintuple nosepiece (detachable); DIN slot |
| Stage: | Top-grade dedicated circular graduated stage. Rotatable 360° horizontally; can be fixed at a specific position. Graduated 360° (in 1° increments); Click stops each 45°. Attachable mechanical stage: 35 x 25mm travel; vernier 0,1mm |
| Condenser: | Dedicated strain-free swing-out type; P Achromat N.A. 0,9 |
| Polarizer: | Fixed to the bottom of the condenser holder; with Scale markings |
| Objectives: | CFI P Achromat 4x, 10x, 20x, 40x, 100x CFI LU Plan Fluor Epi P 5x, 10x, 20x, 50x,100x |
| Episcopic Illuminator: | LV-UEPI Universal Epi-illuminator accommodates a 12V-50W illumination transformer. |
| Compensators: | P-CL Standard 1/4 λ & tint plate, quartz wedge or Senarmont compensator can be inserted into intermediate tube slot |
| Power Consumption: | 1,2A/75W |
| Weight: | Approx. 17kg (standard trinocular set) |
